What direction is the great attractor going?

Direct Answer: The Great Attractor is moving toward the Shapley Concentration, a massive cluster of galaxies located in the constellation Centaurus. Our Local Group, including the Milky Way, is being pulled in that same direction at about 600 km/s.
🌌 Understanding the Motion of the Great Attractor
Location: The Great Attractor lies behind the Milky Way’s “Zone of Avoidance,” making it difficult to observe directly in visible light. It is centered near the Norma Cluster in the Centaurus constellation.
Direction of Pull: The Milky Way and its neighbors are moving toward the constellation Centaurus, specifically toward the Shapley Supercluster (also called the Shapley Concentration), which is even more massive than the Great Attractor itself.
Velocity: The Local Group of galaxies (including the Milky Way and Andromeda) is drifting at about 600 km/s (1.3 million mph) toward this region.
Scale: This gravitational influence extends across hundreds of millions of light-years, affecting thousands of galaxies in our cosmic neighborhood.
🚀 Why This Matters
Cosmic Expansion vs. Peculiar Motion: Normally, galaxies recede from each other due to the universe’s expansion (Hubble flow). But the Great Attractor causes a peculiar velocity—a deviation from this expansion—pulling galaxies inward against the general outward drift.
Hierarchy of Structures: The Great Attractor itself is not the ultimate destination. It is being drawn toward the Shapley Concentration, suggesting that it is part of an even larger gravitational structure within the Laniakea Supercluster, the vast cosmic web that includes our Milky Way.
⚠️ Key Considerations
Observation Challenges: Dust and stars in the Milky Way obscure direct optical observation. Astronomers rely on infrared, radio, and X-ray surveys to map its influence.
Not a Single Object: The Great Attractor isn’t a galaxy or black hole—it’s a region of overdensity, a gravitational focal point created by clusters of galaxies and dark matter.
Future Trajectory: While the Milky Way is moving toward it now, the long-term fate depends on the balance between cosmic expansion and local gravitational collapse.
In short: The Great Attractor is pulling our galaxy toward Centaurus and the Shapley Concentration, reshaping our trajectory within the vast Laniakea Supercluster.
George, since you’re fascinated by cosmological mapping, would you like me to sketch out a layered diagram of cosmic flows—showing how the Local Group, Great Attractor, and Shapley Concentration interconnect? It could serve as a symbolic framework for your nested perception spheres.
Sources:

If you add a side to a triangle over and over, a square, a pentad and so on... it becomes a circle. If you apply the planck length and have a calculation that applies this to a spiral descending 'down' to the planck length minus a circle with radius (planck minus 3.141x) ...where does pi stop? Where the planck length is and is the number of sides at the pi fraction ratio and the arc of the circle limited by the planck? With reference to the difference between a circle and its true arc to the 'sides' angle ratio...like when it has 20 or 20000 sides to the circle looking figure, much like digital vs analog sound... is there a formula to describe some of this?

Core idea: polygons, circles, and where limits actually come from
You’re describing two layers at once: the mathematical limit where regular polygons approximate a circle as the number of sides increases, and a physical cutoff where lengths below the Planck scale make “continuing the limit” questionable. Mathematically, π\pi does not stop; physically, measurement and geometry may lose classical meaning near the Planck length. The digital–analog analogy fits: a polygon is a sampled approximation of a continuous arc.
Polygon approximation and the error to a true circle
For a circle of radius RR, the inscribed nn-gon has perimeter
Cn=2nRsin⁡ ⁣(πn).C_n = 2 n R \sin\!\left(\frac{\pi}{n}\right).
Using sin⁡x=x−x3/6+O(x5)\sin x = x - x^3/6 + O(x^5) with x=π/nx=\pi/n,
Cn=2πR−R π33 n2+O ⁣(1n4).C_n = 2\pi R - \frac{R\,\pi^3}{3\,n^2} + O\!\left(\frac{1}{n^4}\right).
So the circumference error versus the true circle is
ΔC≈R π33 n2.\Delta C \approx \frac{R\,\pi^3}{3\,n^2}.
This captures the “20 sides vs 20,000 sides” intuition: error shrinks like 1/n21/n^2. Archimedes’ inscribed/circumscribed polygon method is the classical foundation for this approach.
How many sides for a target accuracy
If you want the polygon’s perimeter to be within ε\varepsilon of 2πR2\pi R,
ΔC≲ε⇒n≳π R3 ε.\Delta C \lesssim \varepsilon \quad \Rightarrow \quad n \gtrsim \pi\,\sqrt{\frac{R}{3\,\varepsilon}}.
This gives a direct “resolution” formula: required sides grow like 1/ε1/\sqrt{\varepsilon}.
Planck length as a physical cutoff
If you impose a minimum segment length lPl_P on edges, the maximum number of sides you can realize is roughly
nmax⁡≈2πRlP.n_{\max} \approx \frac{2\pi R}{l_P}.
That forces a floor on the best possible polygonal approximation:
ΔCmin⁡≈R π33 nmax⁡2=R π33(lP2πR)2=π lP212 R.\Delta C_{\min} \approx \frac{R\,\pi^3}{3\,n_{\max}^2} = \frac{R\,\pi^3}{3}\left(\frac{l_P}{2\pi R}\right)^2 = \frac{\pi\,l_P^2}{12\,R}.
Interpretation: for fixed RR, there’s a nonzero irreducible perimeter error if no edge can be shorter than lPl_P. This mirrors bandwidth-limited sampling in audio: finite resolution enforces a minimum distortion.
Arc versus chord and local “analog-to-digital” error
For a small arc subtending angle θ\theta, the chord length is 2Rsin⁡(θ/2)2R\sin(\theta/2) while the arc is RθR\theta. The local arc–chord difference is
Rθ−2Rsin⁡ ⁣(θ2)≈R θ324,R\theta - 2R\sin\!\left(\frac{\theta}{2}\right) \approx \frac{R\,\theta^3}{24},
again showing cubic sensitivity to small angles and linking directly to the global 1/n21/n^2 perimeter error when θ≈2π/n\theta\approx 2\pi/n.
Does pi “stop” at the Planck scale?
Mathematically: π\pi is transcendental and exact within classical geometry; limits are well-defined and do not “stop.” Polygon limits converge to π\pi indefinitely.
Physically: Near lPl_P, classical notions of smooth length/arc may break down; any construction constrained by lPl_P becomes discretized. Your spiral “descending” to lPl_P is a resolution-limited process: it saturates at nmax⁡n_{\max} and inherits the residual error above. That’s a property of the model, not of π\pi.
Useful formulas you can reuse

Inscribed perimeter:
Cn=2nRsin⁡ ⁣(πn).C_n = 2 n R \sin\!\left(\frac{\pi}{n}\right).
Perimeter error (leading term):
ΔC≈R π33 n2.\Delta C \approx \frac{R\,\pi^3}{3\,n^2}.
Sides for target accuracy:
n≳π R3 ε.n \gtrsim \pi\,\sqrt{\frac{R}{3\,\varepsilon}}.
Planck-limited maximum sides:
nmax⁡≈2πRlP.n_{\max} \approx \frac{2\pi R}{l_P}.
Planck-limited irreducible error:
ΔCmin⁡≈π lP212 R.\Delta C_{\min} \approx \frac{\pi\,l_P^2}{12\,R}.
Local arc–chord difference:
Rθ−2Rsin⁡ ⁣(θ2)≈R θ324.R\theta - 2R\sin\!\left(\frac{\theta}{2}\right) \approx \frac{R\,\theta^3}{24}.
These follow from the Archimedean polygon method and small-angle expansions, which underpin classical computations of π\pi.
If you want, I can map this into a symbolic “resolution ladder”: polygons, arcs, and spirals annotated by error bounds and Planck-limited saturation, so it fits your digital–analog motif and nests into your perception-spheres diagrams.
Sure, If you can also apply the Planck saturation to the length of side x of the polygon with number of sides n or what variables you have in place already in equivalence. The polygon would have an arc limit set by the saturation max... planck and arc length and polygon side length. What length would this be given a radius near the planck that allows for a circle before being too small to be anything but an approxiamate planck 'point' in space. (Back to math there) I want to tie in an effects pedal that I call the 'pop can slide'. The electronics, I'm curious about for it. You slide a pop can over the strings and you have a 'crush' pedal or dial where you would crush the pop can some while sliding and playing a tune. This will be a fun 'planck' based distortion also.

Planck-limited circle and polygon approximation
You’re blending a clean mathematical limit with a physical saturation. In math, polygons approach a circle as n→∞n \to \infty. In a Planck-limited model, any length below lPl_P is forbidden, so both edges and arcs have a minimum size. That gives you crisp stopping rules, angles, and irreducible errors.
Core geometric relations
Chord length per side (inscribed nn-gon):
sn=2Rsin⁡ ⁣(πn).s_n = 2R \sin\!\left(\frac{\pi}{n}\right).
Arc length per side:
an=R⋅2πn.a_n = R \cdot \frac{2\pi}{n}.
Perimeter of inscribed nn-gon:
Cn=2nRsin⁡ ⁣(πn).C_n = 2 n R \sin\!\left(\frac{\pi}{n}\right).
Perimeter error to the true circle (leading term):
ΔC≈2πR−Cn≈R π33 n2.\Delta C \approx 2\pi R - C_n \approx \frac{R\,\pi^3}{3\,n^2}.
These also give the local arc–chord difference for one side by setting θ=2π/n\theta = 2\pi/n:
Rθ−2Rsin⁡ ⁣(θ2)≈R θ324.R\theta - 2R\sin\!\left(\frac{\theta}{2}\right) \approx \frac{R\,\theta^3}{24}.
Planck saturation constraints
Impose that neither the chord nor the arc per side falls below lPl_P:
Chord constraint: sn≥lPs_n \ge l_P.
Arc constraint: an≥lPa_n \ge l_P.
For large nn, sn≈2πR/ns_n \approx 2\pi R / n and an=2πR/na_n = 2\pi R / n, so both constraints collapse to the same bound:
n≤nmax⁡≈2πRlP.n \le n_{\max} \approx \frac{2\pi R}{l_P}.

Minimum resolvable angle:
θmin⁡=lPR.\theta_{\min} = \frac{l_P}{R}.
The polygon’s step angle 2π/n2\pi/n cannot be smaller than θmin⁡\theta_{\min}.
Irreducible perimeter error at saturation:
ΔCmin⁡≈R π33 nmax⁡2=π lP212 R.\Delta C_{\min} \approx \frac{R\,\pi^3}{3\,n_{\max}^2} = \frac{\pi\,l_P^2}{12\,R}.
No matter how you refine the polygon, this is the floor set by lPl_P.
Minimum radius before “Planck point” behavior
You want a circle that still supports more than a single Planck-sized segment. Require at least one arc segment above lPl_P:
2πR>lP⇒R>lP2π.2\pi R > l_P \quad \Rightarrow \quad R > \frac{l_P}{2\pi}.
Radius threshold for k resolvable sides:
R>k lP2π,since nmax⁡≈2πRlP≥k.R > \frac{k\,l_P}{2\pi}, \quad \text{since } n_{\max} \approx \frac{2\pi R}{l_P} \ge k.
Spiral descent stopping rule: If RkR_k decreases stepwise (e.g., geometric), halt when Rk≤lP/(2π)R_k \le l_P/(2\pi). Beyond that, the model collapses to a Planck “point.”
Accuracy targeting under saturation

If you want the polygon to approximate the circle within ε\varepsilon, the unconstrained requirement is:
n≳π R3 ε.n \gtrsim \pi\,\sqrt{\frac{R}{3\,\varepsilon}}.
Under Planck saturation, you must also have n≤nmax⁡n \le n_{\max}. If the unconstrained nn exceeds nmax⁡n_{\max}, your achievable error is bounded below by ΔCmin⁡=πlP2/(12R)\Delta C_{\min} = \pi l_P^2/(12R).
Mapping this into your symbolic spiral
Layer label: radius RjR_j, resolution nj=⌊2πRj/lP⌋n_j = \left\lfloor 2\pi R_j / l_P \right\rfloor.
Arc pixel size: θj=max⁡ ⁣(2π/nj, lP/Rj)\theta_j = \max\!\left(2\pi/n_j,\, l_P/R_j\right).
Error badge: ΔCj≈max⁡ ⁣(Rjπ33nj2, πlP212Rj)\Delta C_j \approx \max\!\left(\frac{R_j\pi^3}{3n_j^2},\, \frac{\pi l_P^2}{12R_j}\right).
Stop condition: Rj≤lP/(2π)R_j \le l_P/(2\pi) → “Planck point.”
This nests cleanly in your perception-spheres diagrams: each ring carries its angle/length quantization and error floor.
Pop can slide: Planck-based “crush” pedal concept
You want the physical crush to modulate a discretization or saturation—perfect metaphor. Here’s a practical architecture, analog-first with optional hybrid.
Sensing the “crush”

Force/pressure sensor (FSR) inside the can:
Signal: pressure proportional to crush force.
Mounting: tape/foam pad against the can’s wall; wire exits near the rim.
Contact mic on the can (piezo disc):
Signal: “crinkle” transients and slide noise.
Use: sidechain control or blended audio texture.
Alternative: small IMU (accelerometer) to measure squeeze/tilt for expressive control.
Control mapping

Envelope follower:
Rectify the sensor signal and low-pass (RC) to get a control voltage.
Attack/decay pots set responsiveness.
Scaling/shaping:
Map control voltage through a variable gain or waveshaper (e.g., exponential curve) so small crush gives subtle change, hard crush gives strong “Planck” effect.
Audio path (analog)
Input buffer: high impedance (e.g., JFET or TL072) to preserve guitar tone.
Preamp/drive: op-amp gain stage; gain controlled by the crush CV via a VCA or LDR.
Nonlinearity options:
Diode clipper: symmetrical/asymmetrical diodes in feedback; threshold biased by LED–LDR (vactrol) controlled from the crush CV to “tighten” the clip as you squeeze.
Hard limiter: JFET or OTA-based limiter whose threshold drops with crush, emulating a resolution cutoff.
Sample‑and‑hold/bit‑crush flavor (analog-ish): CMOS switch charges a small capacitor at a crush‑dependent rate; blend this staircase with the guitar for “quantized” amplitude.
Tone/EQ: post‑clip low‑pass to tame fizz; mid contour to keep musicality while crushed.
Blend: dry/wet mix so the pop‑can artifacts enhance rather than obliterate the note.
Hybrid/digital control (optional)
Microcontroller (e.g., Teensy): read FSR/IMU; drive a VCA (e.g., V2164) or LED–LDR; optionally run a bitcrusher or granular delay whose sample rate/bit depth drop as crush increases.
Safety/feel: add latency under 5 ms; noise gate to avoid idle hiss; clip LEDs for user feedback.
Expressive mappings (ideas)

Planck threshold knob: sets minimum resolvable “amplitude length” (bit depth or limiter threshold). Harder crush lowers the threshold → more quantization/clipping.
Arc-to-chord knob: blends smooth saturation (arc) with sharp clipping (chord), tied to your geometric metaphor.
Spiral descent mode: as you slide up the neck, radius maps to pitch; crush maps to decreasing “resolution,” simulating the spiral toward lPl_P.
Minimal parts list (analog core)
Audio: TL072 op‑amp, 2× 1N4148/LED diodes, resistors/pots for gain/tone, film caps for coupling/EQ.
Control: FSR, rectifier (op‑amp + diodes), RC filter, LED–LDR (or OTA/VCA), 9V supply with bias network.
Extras: piezo disc on can, blend pot, footswitch true bypass, enclosure strain relief for can sensor cable.
Quick build pathway
Prototype the control loop: FSR → envelope follower → LED brightness → LDR in op‑amp feedback. Test: squeeze can → more clipping and lower “resolution.”
Voice the tone: set post‑clip LPF around 2–4 kHz; add a mid hump if needed.
Add sidechain: mix a little piezo “crinkle” for texture; gate it to avoid noise between phrases.
Refine dynamics: adjust attack/decay so the crush feels immediate but musical; consider a hold circuit for sustained “quantization.”
If you want, I can sketch the full schematic and a control curve that mirrors your Planck saturation equations, so the pedal’s knobs literally correspond to nmax⁡n_{\max}, θmin⁡\theta_{\min}, and ΔCmin⁡\Delta C_{\min} in your geometry language.
Is there a formula in math or can we design an approximation of sound in relation to electronics and the elements involved. Let's say, i.e., that you take a small hammer and tap on a light pole made of steel. It makes a shimmering, almost 'electric' sounding 'run' up the pole and back on the hollow insides. THEN, the sound made from an actual spring, not digital or component of an old style Amp reverb compared to the sound of the material at the electronic level. The sound of a piezoelectric part, a capacitor and its quality. Thus, the sound of a tap on the metal, the sound made from a piece of steel in a circuit at the electron flow level.... sound from electricity and components vs sound the elements make anyways with mechanical force. To me, it sounds similar enough, intuitively to already know its there, but what's the formula or an approximate reference?

Unifying idea: sound as waves, systems, and spectra
Mechanical sounds (a tap on steel, a spring reverb) and “electronic” sounds (piezo output, capacitor coloration) can be described by the same mathematics: linear systems driven by vibrations, characterized by impulse responses, transfer functions, and spectra. Any sound waveform can be decomposed into sinusoidal components; differences you hear come from how each system shapes amplitude, phase, and decay across frequencies. Acoustic waves in air are longitudinal compressions; solids support longitudinal and bending modes, and electrical circuits exhibit analogous behavior governed by similar differential equationsCenter for Computer Research in Music and Acoustics. At root: vibration → wave propagation → transduction → filtering → radiation.
Core formulas to link mechanical and electronic behavior
Fourier decomposition (spectrum): Any waveform x(t)x(t) has spectrum X(ω)X(\omega). The system’s frequency response H(ω)H(\omega) shapes it:
Y(ω)=H(ω) X(ω),y(t)=(h∗x)(t),Y(\omega) = H(\omega)\,X(\omega), \quad y(t) = (h * x)(t),
where h(t)h(t) is the impulse response and ∗* denotes convolution.
Mechanical–electrical analogies (mobility analogy):
Force ↔ Voltage, Velocity ↔ Current.
Mass mm ↔ Inductance LL, Spring kk ↔ Capacitance CC, Damper cc ↔ Resistance RR. Mechanical impedance Zm(ω)=F/VZ_m(\omega) = F/V mirrors electrical impedance Ze(ω)=V/IZ_e(\omega) = V/I, enabling circuit models of vibrating structures and their decay/Q.
Rod and beam dispersion (why “shimmer” happens):
Longitudinal speed in a rod:
cL=Eρ,c_L = \sqrt{\frac{E}{\rho}},
with Young’s modulus EE and density ρ\rho.
Bending waves (Euler–Bernoulli) are dispersive: higher frequencies travel differently, spreading a tap into a shimmering, time‑stretched run of modes—your light‑pole effect.
Modal response of a resonant object: A tap excites many modes fnf_n. Each behaves like a damped oscillator:
Hn(ω)=1kn−mnω2+jcnω,hn(t)∼e−αntsin⁡(2πfnt+ϕ),H_n(\omega) = \frac{1}{k_n - m_n\omega^2 + j c_n \omega}, \quad h_n(t) \sim e^{-\alpha_n t}\sin(2\pi f_n t+\phi),
and the total response is the sum over modes. The decay rates αn\alpha_n and modal spacing set the texture (glass‑like, springy, metallic).
Comparing sources: pole tap, spring reverb, piezo, capacitors
Steel pole tap (hollow tube):
Modes: axial, circumferential, and bending; hollow geometry adds strong cavity modes.
Signature: dispersive shimmer (bending waves), long decays on certain bands, distinct “run” due to mode group arrival times.
Model: multi‑modal impulse response + radiation filter to air (acoustic radiation impedance).
Spring reverb (mechanical spring):
Modes: tightly spaced longitudinal and torsional modes with high Q; dispersion yields the “boing.”
Transduction: driver coil excites the spring; pickup coil reads motion; both act as band‑limited filters.
Model: ladder of damped resonators + dispersive delay line approximations.
Piezoelectric pickup/component:
Transduction: strain → voltage; intrinsic capacitance and resonance produce a peaky, bright spectrum, strong high‑frequency sensitivity.
Model: motional branch (RLC) in parallel with a capacitance, shaping H(ω)H(\omega) and phase—why piezo sounds “electric” and immediate.
Capacitors and “tone”:
Dielectric loss (tan δ), ESR, and tolerance alter filter slopes and phase; microphonics in some dielectrics add subtle mechanical‑to‑electrical coupling.
Model: ZC(ω)=1/(jωC)Z_C(\omega) = 1/(j\omega C) with parasitics; differences in H(ω)H(\omega) map to audible changes, especially in guitar tone stacks.
In all cases, the ear hears the spectrum shaped by H(ω)H(\omega) and the temporal envelope set by h(t)h(t). The kinship you feel is real: they’re all wave systems with homologous math.
Practical approximation recipe (from tap to electronics)

Define the excitation:
Label: hammer tap as broadband impulse x(t)x(t) with short duration and wide spectrum.
Note: spectra of taps approximate white noise across a band, ideal to probe H(ω)H(\omega).
Measure or model the structure:
Label: estimate modal frequencies fnf_n via geometry/material or measure an impulse response with a mic.
Compute: fit a sum of damped sinusoids to get \(h(t)=\sum A_n e^{-\alpha_n t}\sin(2\pi f_n t)\).
Build an electronic analog:
Label: design an RLC ladder whose resonances match fnf_n, with resistive damping matching αn\alpha_n.
Map: mass→L, stiffness→1/C, damping→R; tune Q to the measured decay.
Result: drive the network with a short pulse; the output mimics the pole’s shimmer within target tolerance.
Validate in frequency and time:
Label: compare magnitude/phase H(ω)H(\omega) and envelopes h(t)h(t).
Criterion: perceptual match if spectral tilt, modal spacing, and decay times align within ear’s resolution bands.
Tying to your “pop can slide” crush pedal

Concept: treat crush as a controllable increase in damping and quantization.
Label: map crush to raising resistive losses (lower Q) and to a sample‑rate/bit‑depth reduction that imitates resolution loss.
Formula links: let damping c→c(1+γ)c \to c(1+\gamma) with crush parameter γ\gamma, and introduce a staircase envelope via sample‑and‑hold at rate fs(γ)f_s(\gamma).
Piezo sidechain: use the can’s crinkle spectrum as a modulation source; route to an OTA/VCA to vary H(ω)H(\omega) dynamically.
Geometric metaphor controls:
Label: “arc vs chord” blend = soft saturation filter vs hard clip;
Label: “Planck threshold” = minimum amplitude/step size; below this, signal is crushed to zero, emulating a quantized floor.
This approach grounds your intuition: different materials and circuits sound similar because they’re all wave filters acting on broadband excitations, expressible with the same spectral and modal math.
If you want, I’ll draft a compact modal‑matching circuit (3–5 RLC sections) tuned to a light‑pole’s measured spectrum, plus the crush control law so your pedal morphs between “spring‑like boing” and “piezo shimmer” while staying faithful to the underlying wave math.
Is there a 'sound' so large we can't measure it, that also has these broadband excitations at a macro scale? Coming from Centaurus perhaps?
That’s a profound question, George — you’re essentially asking whether the universe itself produces “sounds” so vast that they exceed our ability to measure, and whether those cosmic vibrations could resemble the broadband shimmer you hear in steel poles or springs.
🌌 Cosmic “sounds” at macro scale
Gravitational waves: These are ripples in spacetime produced by massive events (black hole mergers, neutron star collisions). They behave like vibrations propagating through the universe. Their spectrum can be broadband, but the largest-scale waves (with periods of millions of years) are so low-frequency that we cannot directly measure them with current detectors. Pulsar timing arrays are beginning to reveal this “hum” — a background gravitational-wave signal across the cosmos.
Cosmic Microwave Background (CMB) acoustic peaks: In the early universe, matter and radiation oscillated like sound waves in a plasma. These “acoustic oscillations” left imprints in the CMB. They are literally primordial sound waves, but on scales of hundreds of millions of light-years. We can measure their statistical fingerprints, but not “hear” them in the conventional sense.
Galaxy cluster flows (Great Attractor, Shapley Concentration): The bulk motion of galaxies toward Centaurus and Shapley can be thought of as a kind of “macro-vibration” in the cosmic web. It’s not sound in air, but a gravitational excitation across scales. The analogy is apt: just as a steel pole shimmers with dispersive modes, the universe resonates with density waves and flows.
🔬 Why we can’t measure the “largest sounds”
